Surveillance Ball BKQ01
Intelligent Integration: Supports seamless switching across multiple networks and location tracking, enabling a command-and-control capability characterized by "full-domain connectivity and intelligent collaboration."
High-Definition Surveillance: Equipped with a 30x digital high-definition camera for continuous 24/7 high-resolution recording at fixed positions, meeting demanding detailed surveillance requirements.
Highly Protective Design: Lenses are safeguarded against rain, fog, wind, and dust, ensuring reliable operation in harsh environments such as heavy rainfall, dust storms, and extreme heat.
Applications:
|
|
|
|
Core Features:
Efficient Coding & Multi-ResolutionAdaptability: Supports Hanghk-H.265+/H.264+ dual-stream compression encoding, intelligently switching codecs based on network conditions to balance video quality and transmission efficiency. Simultaneously delivers multi-resolution outputs including 1080P and 720P, meeting diverse visual requirements for high-definition live streaming, remote monitoring, and other applications. | Wide-Temperature Durability &Portable Design: Operates reliably across an extreme temperature range of -30°C to 75°C and humidity levels from 20% to 95% RH (non-condensing), performing stably in frigid, high-temperature, or humid environments. Compact dimensions (≤140×80×40 mm) and lightweight construction enable easy carry, with mounting options for tactical vests or backpacks to meet mobile field operation demands. |
Extended Endurance & Wide Voltage Compatibility: Features DC 9–16V wide-voltage input, powered by an external high-capacity lithium battery for over 5 hours of continuous operation (power consumption ≤4W), balancing energy efficiency with prolonged mission capability. Includes a slide-out SIM/UIM card tray for rapid field replacement, ensuring stable network connectivity. | Multi-Interface Expansion & Professional Equipment Compatibility: Beyond standard HDMI and Ethernet ports, provides dedicated external audio/video input ports and a thermal imager interface. Seamlessly integrates with thermal imaging devices, external microphones, and other specialized gear, fulfilling unique requirements for night reconnaissance, special operations, and critical missions. |
Product Specifications:
Remote Operations: Supports remote configuration for screenshot capture, video recording, multi-client real-time audio/video preview, and remote file download (audio/video); enables firmware updates via remote access. Customizable Settings: Allows remote adjustment of bitrate, frame rate, resolution, image quality, and OSD (On-Screen Display) overlay; consolidates multiple connection cables into a single-interface solution. Lens Protection: Features rainproof, fog-resistant, windproof, and dustproof design. Advanced Compression: Supports Hanghk-H.265+/H.264+ dual-stream encoding with selectable resolutions including 1080P, 720P, and D1. Control & Connectivity: Enables remote PTZ command transmission (zoom control) and 5G multi-carrier bonding transmission. | Storage & Wireless: Equipped with TF card storage and built-in Wi-Fi module for direct video preview via mobile devices; allows mobile devices to access network through the camera. Sensor Specifications: 1/2.8-inch 3MP progressive scan CMOS sensor; supports resolutions above 1080P. Battery Life: Provides ≥4 hours of operational runtime. Mechanical Design: Features a 360° unlimited-position pan-tilt base. Protection Rating: IP66-rated enclosure. Power Consumption: ≤18 W. |
