Individual Soldier Image Transmission DBTCO1
Strong Compatibility: Supports 4G/5G full-network compatibility, adapting to diverse networking requirements across multiple scenarios to ensure smooth audio/video transmission.
Rich Connectivity Options: Equipped with HDMI 2.0/HDMI 2.1 ports, Ethernet ports, and other interfaces, meeting data transmission and connection needs for various devices.
High Integration Level: Features a built-in microphone and speaker, eliminating the need for external audio equipment and facilitating portable, single-operator deployment.
Applications:
|
|
|
|
Core Features:
Efficient Coding & Multi-ResolutionAdaptability: Supports Hanghk-H.265+/H.264+ dual-stream compression encoding, intelligently switching codecs based on network conditions to balance video quality and transmission efficiency. Simultaneously delivers multi-resolution outputs including 1080P and 720P, meeting diverse visual requirements for high-definition live streaming, remote monitoring, and other applications. | Wide-Temperature Durability &Portable Design: Operates reliably across an extreme temperature range of -30°C to 75°C and humidity levels from 20% to 95% RH (non-condensing), performing stably in frigid, high-temperature, or humid environments. Compact dimensions (≤140×80×40 mm) and lightweight construction enable easy carry, with mounting options for tactical vests or backpacks to meet mobile field operation demands. |
Extended Endurance & Wide Voltage Compatibility: Features DC 9–16V wide-voltage input, powered by an external high-capacity lithium battery for over 5 hours of continuous operation (power consumption ≤4W), balancing energy efficiency with prolonged mission capability. Includes a slide-out SIM/UIM card tray for rapid field replacement, ensuring stable network connectivity. | Multi-Interface Expansion & Professional Equipment Compatibility: Beyond standard HDMI and Ethernet ports, provides dedicated external audio/video input ports and a thermal imager interface. Seamlessly integrates with thermal imaging devices, external microphones, and other specialized gear, fulfilling unique requirements for night reconnaissance, special operations, and critical missions. |
Product Specifications:
Temperature Range: -30°C to 75°C Humidity Range: 20% to 95% RH (non-condensing) Dimensions: ≤140×80×40 mm Compression Formats: Supports Hanghk-H.265+/H.264+ dual-stream compression encoding. Transmission Resolutions: Multiple options including 1080P, 1080I, 720P, and D1. SIM/UIM Card Slot: Slide-out tray design for easy replacement. Power Consumption: ≤4W. | Power Supply: DC 12V input (operates within DC 9–16V range); external high-capacity lithium battery provides over 5 hours of continuous operation. Ethernet port support; Full compatibility with 4G/5G networks; External audio/video input ports; Dedicated interface for connecting thermal imagers. Integrated Hardware: As a cellular network-based individual audio/video capture device, it includes built-in microphone and speaker. |
